On 9th January, the F-100 class frigate “Cristóbal Colón”, under construction in Navantia for the Spanish Navy, left the shipyard dry dock after a period of dry docking for hull and platform readiness for sea trials, that will take place in March 2012.
During this month, Navantia will proceed to the completion of the Combat System integration functional trials, in order to have the sea trials in May. The frigate is now in the final phase of construction, and after the sea trials it is expected to be commissioned next July.
The fifth frigate incorporates new solutions and technology that will fullfill the most demanding challenges for present and future threats:
- Multipurpose Vessel excellent performance in all types of sea states Multipurpose ship
- Medium-size ocean escort vessel.
- Optimised for operating as flagship in conflict scenarios with capability to be part of an allied fleet and support expeditionary forces.
- Capability to flexibly operate in littoral waters or high seas conditioned to conflict challenges.
- High air warfare capability.
It also incorporates important improvements in systems and equipment:
- Lockheed Martin Aegis System linked to Radar SPY-1D (V).
- Integration of new Spanish sensors and weapons into the Aegis System by means of a new version of CDS developed by Navantia- FABA Systems.
- New IPMS developed by Navantia – FABA Systems.
- Updated system of the Navigation Data Distribution Network.
- Navantia/Caterpillar Bravo 16V propulsion engines.
- RAS sliding padeyes.
- Retractable bow thruster for ship manoeuvring and emergency.
Technical features
- Waterline Length ………………………. 133.20 m
- Full Load Displacement …………………. 6,041 t
- Full Load Draught …………………………. 5.00 m
- Maximum speed ……………………… 28.5 knots
- Cruising speed ………………………….. 18 knots
- Endurance at Cruising Speed ……. 4,500 miles
- Crew …………………………………… 234 persons
Shipbuilding Specs
- Number of compartments: 573
- Tons of Hull Steel: 2,450 t.
- Metres of cable: 315,000 m.
- Metres of piping: 37,000 m.
